System 3

System 3

$20,264.00
$20,264.00
Condition Brand New
Specs Verified model facts
Checked against 1 listing
Verified
Use Professional mixing and post-production facilities that want multiple channels of Bricasti M7-class hardware reverb (three true-stereo engines running simultaneously) controlled from a single M10 console at the mix position.
Requires compatible power supply or battery, instrument and patch cables
In stock Ask a question

Specifications

True stereo reverb processing · Dual dedicated supplies per M7M: custom toroidal transformer (analog), switching supply (digital)

System Contents

Reverb processors 3x Bricasti M7M stereo reverb processor mainframes
Remote console 1x Bricasti M10 Remote console
Serial cable 10-meter RS422 serial cable included
Interconnect cables 2x 25 cm interconnect cables

Reverb Engine

Presets 100 unique reverb presets (halls, plates, rooms, chambers, ambient spaces)
Program parameters 12 parametric program parameters
User registers 100
Front-panel favorites 4 front-panel favorites for quick saves
Process type True stereo reverb processing
DSP 6 dual-core Analog Devices DSPs (per M7M)

Digital Audio (per M7M)

Digital I/O AES 24-bit digital I/O; AES single-wire 192k supported
Sample rates Self-clocking to incoming sample rates 44.1 kHz to 192 kHz
Jitter Less than 20 picoseconds jitter

Analog Audio (per M7M)

Analog I/O Balanced XLR analog I/O, fully balanced DC-coupled input and output circuits
Conversion 24-bit conversion, dual D/A
Input level adjustment Adjustable in 2 dB steps
Dynamic range >116 dB A-weighted (input and output)
THD+N <0.001
Frequency response 10 Hz - 20 kHz, +/- <0.05 dB
CMRR >60 dB at <= 1 kHz
Maximum input level +24
Maximum output level +24
Minimum input for 0 dBFS +4

Control & Connectivity

Remote interface RS422 serial interface between M10 and M7M units
Units controllable by M10 M10 controls up to 8 M7-series units
Maximum serial cable run Up to 30 meters possible (10-meter cable provided)
Metering 8 dedicated meters for 4 stereo pairs on M10
MIDI MIDI I/O

Construction & Power

Power supplies Dual dedicated supplies per M7M: custom toroidal transformer (analog), switching supply (digital)
Chassis Stainless steel chassis with milled anodized aluminum front panel
M10 casing Milled from solid anodized aluminum
Country of manufacture Hand-crafted in the USA

Fit and constraints

Professional mixing and post-production facilit… · Dual dedicated supplies per M7M: custom toroidal transformer (analog), switching supply (digital)

Intended use

Use Professional mixing and post-production facilities that want multiple channels of Bricasti M7-class hardware reverb (three true-stereo engines running simultaneously) controlled from a single M10 console at the mix position. Suited to engineers working in AES digital at up to 192 kHz or via balanced analog XLR, who value dedicated hardware reverb over plugins.
Not for Anyone needing only one reverb channel (Bricasti's System 1 pairs a single M7M with the M10), home/project studios without an analog console or AES routing to feed three stereo processors, and buyers expecting DAW plugin-style recall or USB/network integration — control is via the M10 hardware remote and MIDI, not a computer.

Constraints

PowerDual dedicated supplies per M7M: custom toroidal transformer (analog), switching supply (digital)
ControlsThe M7M has no full front-panel control set, so units are of limited use without an M10...

To use it

Required compatible power supply or battery, instrument and patch cables

Questions

3 to ask before buying

What voltage, polarity, and current does this exact revision require?

Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.

Are the original box, power supply, and any model-specific accessories included?

Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.

Does this listing match the exact revision and finish shown in the source photos?

Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.

Description

Product details

The Bricasti Design System 3 is a hardware reverb processing bundle consisting of three M7M stereo reverb processor mainframes and one M10 remote console, supplied with a 10-meter serial cable and two 25-centimeter interconnect cables. The M7M is an exact duplicate of the Bricasti M7 stereo reverb processor with reduced front-panel controls, designed to be operated from the M10 Remote Console over an RS422 serial interface. Each M7M provides 100 reverb presets covering halls, plates, rooms, chambers, and ambient spaces, with 12 parametric program parameters and 100 user registers, processed by six dual-core Analog Devices DSPs. Audio I/O is 24-bit AES digital (self-clocking from 44.1 kHz to 192 kHz, single-wire 192k supported) plus balanced XLR analog with 24-bit conversion and greater than 116 dB A-weighted dynamic range. The units are hand-crafted in the USA with stainless steel chassis and milled anodized aluminum panels.
