DAD DX32R is a 1U rackmount digital audio bridge and routing matrix from Digital Audio Denmark that interconnects Dante IP audio, MADI and AES3 networks without analog conversion.
Specifications
Function and Format
| Product type | Digital audio bridge, format converter and routing matrix for Dante, MADI and AES3 |
|---|---|
| Rack format | 1U 19-inch rackmount |
| Routing matrix | 384 x 384 mono-channel multiplexer with near-zero latency |
| Status | Discontinued; replaced by NTP Penta 721S |
Digital I/O
| Aes3 | 8 AES3 I/O interfaces (16 channels I/O) |
|---|---|
| Madi coax | 1 MADI coax I/O (64 channels I/O) |
| Madi optical | 2 optional MADI optical I/O (up to 128 channels I/O) |
| Dante | Ethernet IP audio interface, 64 I/O channels using Dante |
| Aes sample channels | AES counts: 64 channels at 48 kHz, 32 at 96 kHz, 16 at 192 kHz |
Clocking and Power
| Clock | Internal clock and PLL with sync via word clock, AES11, video and all digital I/O (sibling AX32 documentation) |
|---|---|
| Power | Dual redundant power supply as standard |
Control
| Control software | DADman control software for Windows and macOS over Ethernet |
|---|---|
| Use cases | Multi-room recording studios, post-production facilities and audio distribution installations |
Fit and constraints
Intended use
Constraints
To use it
Questions
Which connections, drivers, operating systems, and sample rates are supported by this exact revision?
Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.
What cables, mounts, power supplies, or licenses are included?
Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.
Is the current retailer listing new stock, demo stock, open box, or special order?
Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.
Description
The DX32R is a 1U rackmount digital audio bridge that routes Dante IP audio, MADI, and AES3 signals through a 384-channel multiplexer with near-zero latency. It features eight AES3 I/O interfaces, one MADI coax input/output, two optional MADI optical connections, and 64 Dante channels. The unit supports various sample rates up to 192 kHz and includes internal clock synchronization with word clock and AES11 sync options. Now discontinued and replaced by the NTP Penta 721S.
