A tall, slim white lacquer Grimm Audio LS1v2 active loudspeaker, its narrow rectangular cabinet suspended between two curved half-cylinder legs that form an integrated floor stand.

GRIMM AUDIO LS1v2 (White Lacquer) — Studio Monitor

$30,495.00
$30,495.00
Skip to product information
A tall, slim white lacquer Grimm Audio LS1v2 active loudspeaker, its narrow rectangular cabinet suspended between two curved half-cylinder legs that form an integrated floor stand.
  • A tall, slim white lacquer Grimm Audio LS1v2 active loudspeaker, its narrow rectangular cabinet suspended between two curved half-cylinder legs that form an integrated floor stand.
  • GRIMM AUDIO LS1v2 (White Lacquer) — Studio Monitor, nearfield reference loudspeaker
  • GRIMM AUDIO LS1v2 (White Lacquer) — Studio Monitor, nearfield reference loudspeaker
  • A tall, slim white lacquer Grimm Audio LS1v2 active loudspeaker, its narrow rectangular cabinet suspended between two curved half-cylinder legs that form an integrated floor stand.
  • GRIMM AUDIO LS1v2 (White Lacquer) — Studio Monitor, nearfield reference loudspeaker
  • GRIMM AUDIO LS1v2 (White Lacquer) — Studio Monitor, nearfield reference loudspeaker
GRIMM AUDIO LS1v2 (White Lacquer) — Studio Monitor

GRIMM AUDIO LS1v2 (White Lacquer) — Studio Monitor

Active floorstanding monitor with 8-inch magnesium woofer and 1-inch tweeter, powered by dual 180W Class D amps and DSP-based calibration. Reproduces down to 35 Hz and includes both digital/analog inputs plus subwoofer output.

$30,495.00
$30,495.00
Condition Brand New
Specs Verified model facts
Checked against 1 listing
Verified
Use Mastering and mixing engineers, and high-end hi-fi listeners, who want a phase-linear, DSP-calibrated active monitor that works as a complete system needing only a digital or analog line source.
Requires appropriate audio and data cables, compatible monitoring, mounting, or power setup
In stock Ask a question

Specifications

Class D (Hypex NCore) · Two 180W amplifiers per speaker

Drivers

Woofer 8" magnesium (Seas)
Tweeter 1\" dome
Driver Brand Audiophile-quality Seas drivers
Configuration Two-way active

Amplification

Amplifier Power Two 180W amplifiers per speaker
Amplifier Type Class D (Hypex NCore)
Idle Power Consumption 16 W per speaker at idle

Acoustic Performance

Low-Frequency Extension (standalone) Bass response down to 35 Hz (without subwoofers)
Frequency Response 20 Hz - 27 kHz (+0.5 / -3 dB)
Maximum SPL Approx. 105 dB at 1 metre
Signal-to-Noise Ratio 114 dB (unweighted)
Unidirectional Response Unidirectional response down to 250 Hz

Crossover & DSP

Crossover Frequency 1550 Hz
Crossover Slope LR4 acoustic slopes, IIR with inverted all-pass phase correction
DSP 48/76-bit DSP with Computer Aided Calibration
Clock Circuit Clock circuit shared with the Grimm Audio CC1 master clock

Cabinet & Dimensions

Cabinet Type Sealed box, 14 litres, wider than deep
Width 52 cm (520 mm)
Height 115 cm (hi-fi leg height); studio height version approx. 145 cm
Depth 16 cm (160 mm)
Stand Cabinet suspended between two half-cylinder legs functioning as an integral floor stand

Connectivity & Control

Inputs Digital I/O and analog line inputs
Subwoofer Output DSP-filtered analog subwoofer output
Control Remote control of volume and settings
Max Analog Input 19 dBu max analog input

Protection & Warranty

Warranty 5-year limited warranty

Finish

Finish (this variant) White Lacquer
Finishes Available White lacquer, black lacquer, caramel bamboo veneer, natural bamboo veneer, custom RAL colors

Fit and constraints

Mastering and mixing engineers, and high-end hi… · Two 180W amplifiers per speaker · 52 cm (520 mm)

Intended use

Use Mastering and mixing engineers, and high-end hi-fi listeners, who want a phase-linear, DSP-calibrated active monitor that works as a complete system needing only a digital or analog line source. The integrated floor-stand cabinet and unidirectional dispersion down to 250 Hz suit rooms where controlled off-axis response and accurate low-mid reproduction matter.
Not for Anyone needing a compact, nearfield, or portable monitor, or working on a modest budget - this is a large floorstanding system at roughly 30,495 CAD. Those requiring deep sub-bass below 35 Hz from the speaker alone should skip it or plan to add subwoofers via the filtered subwoofer output. Buyers wanting passive speakers or traditional standmount placement flexibility should also look elsewhere.

Constraints

PowerTwo 180W amplifiers per speaker
Board space52 cm (520 mm)
ControlsSources disagree on amplifier rating: the manufacturer and most retailers state two 180...

To use it

Required appropriate audio and data cables, compatible monitoring, mounting, or power setup

Questions

3 to ask before buying

Which connections, drivers, operating systems, and sample rates are supported by this exact revision?

Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.

What cables, mounts, power supplies, or licenses are included?

Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.

Is the current retailer listing new stock, demo stock, open box, or special order?

Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.

Description

Product details

The Grimm Audio LS1v2 is an active two-way floorstanding studio monitor and hi-fi loudspeaker sold individually or as a stereo pair. Each cabinet pairs an 8-inch magnesium woofer with a 1-inch dome tweeter, driven by two 180W Hypex NCore Class D amplifiers and a 48/76-bit DSP that performs Computer Aided Calibration, phase correction, and an LR4 crossover at 1550 Hz. The sealed 14-litre cabinet is suspended between two half-cylinder legs that act as an integrated floor stand, and it accepts both digital and analog inputs while offering a filtered analog subwoofer output. It reproduces bass down to 35 Hz on its own and includes excursion and thermal driver protection.
