Hammond A-162 console organ with two waterfall manuals, harmonic drawbars, reverse-color preset keys, and a detachable 25-note pedalboard in a compact wooden console cabinet.

HAMMOND A-162 — Synthesizer

$20,540.00
$20,540.00
Skip to product information
Hammond A-162 console organ with two waterfall manuals, harmonic drawbars, reverse-color preset keys, and a detachable 25-note pedalboard in a compact wooden console cabinet.
  • Hammond A-162 console organ with two waterfall manuals, harmonic drawbars, reverse-color preset keys, and a detachable 25-note pedalboard in a compact wooden console cabinet.
  • HAMMOND A-162 — Synthesizer
  • HAMMOND A-162 — Synthesizer
  • Hammond A-162 console organ with two waterfall manuals, harmonic drawbars, reverse-color preset keys, and a detachable 25-note pedalboard in a compact wooden console cabinet.
  • HAMMOND A-162 — Synthesizer
  • HAMMOND A-162 — Synthesizer
HAMMOND A-162 — Synthesizer

HAMMOND A-162 — Synthesizer

$20,540.00
$20,540.00
Condition Brand New
Specs Verified model facts
Checked against 1 listing
Verified
Use Churches, chapels, schools, and home or studio organists who want authentic B-3-style Hammond drawbar tone in a single self-contained console — Hammond markets the A-162's small footprint specifically for these settings.
Requires compatible power and data connections, monitoring or MIDI setup as required
In stock Ask a question

Specifications

Waterfall keyboards · 150-watt onboard sound system

Sound Engine

Tone Generator 2 × VASE III as digital tonewheels
Polyphony 61-note polyphony
Engine Lineage Same VASE III tonal engine as the Hammond B-3mk2
Manual Voicing 5 choices (B-Type1, B-Type2, Mellow, Brite, Sawtooth) with variable key-click
Pedal Voicing 4 choices (Normal, Muted, Synth1, Synth2)

Keyboards & Pedalboard

Swell Manual 73 keys (C1-C6 61 playing keys + 12 preset keys)
Great Manual 73 keys (C1-C6 61 playing keys + 12 preset keys)
Key Type Waterfall keyboards
Pedalboard 25-note radiating, detachable

Drawbars & Presets

Swell Drawbars 9 pitches
Great Drawbars 9 pitches
Pedal Drawbars 2 pitches
Preset Capacity 12 banks, 11 presets per manual
Preset Keys Reverse-color preset keys, as on classic B-3/C-3/A-100

Effects

Percussion Touch-Response Percussion; buttons Second, Third, Fast, Soft; adjustable touch, velocity, decay, level
Internal Leslie Advanced Digital Leslie, 2 rotors; Brake/On/Fast buttons
Vibrato & Chorus Digital scanner; rotary mode knob V1, V2, V3, C1, C2, C3; independent Swell/Great on-buttons
Overdrive Digital
Reverb Digital, 11 programs
Equalizer Bass, Mid (sweep), Treble, Tone

Amplification & Speakers

Amplifier 3 × 50-watt RMS amplifiers
Total Onboard Power 150-watt onboard sound system
Speakers Five heavy-duty speakers
Speaker Complement 8-inch and 6-inch full-range drivers plus 15-inch woofer

Connectivity & Control

MIDI In, Out; 3 templates; 1 internal and 1 external zone per keyboard
Audio I/O Line In L/R, Microphone In with volume control, Line Out L/R, Headphones
External Leslie 11-pin connector, 1 to 3 channels
Pedals & Switches Expression pedal with 1 foot switch; optional CU-1 console foot switch
Storage CompactFlash card slot
Display 20-character, 2-line; 9 control buttons and value knob
Tuning & Transpose Master tune 430-450 Hz in 1 Hz steps; transpose -6 to +6 semitones
Couplers Pedal to Great, Great to Pedal, Pedal to Swell (adjustable highest note)

Dimensions & Weight

Dimensions (console) 38" H × 47" W × 25.5" D (without rack and pedalboard)
Dimensions (with pedalboard) 45" H × 47" W × 36.5" D (with rack and pedalboard)
Weight (console) Console 200 lbs
Weight (pedalboard) Pedalboard 76 lbs
Weight (bench) Bench 42 lbs

Fit and constraints

Churches, chapels, schools, and home or studio … · 150-watt onboard sound system

Intended use

Use Churches, chapels, schools, and home or studio organists who want authentic B-3-style Hammond drawbar tone in a single self-contained console — Hammond markets the A-162's small footprint specifically for these settings. Its 150-watt five-speaker system with 15-inch woofer means no external amplification is needed, the 25-note pedalboard and Pedal/Great/Swell couplers suit traditional two-manual-and-pedals playing, and the built-in two-rotor Digital Leslie delivers rotary effect without a cabinet (an 11-pin jack supports a real Leslie later).
Not for Anyone shopping for an actual synthesizer — despite the catalog title, this is a digital tonewheel console organ, not a synth (drawbars, percussion, chorus-vibrato; no synthesis engine beyond two 'Synth' pedal voicings). Also a poor fit for gigging players: the console alone weighs 200 lbs, plus a 76-lb pedalboard and 42-lb bench per the owner's manual. Players who already own amplification and a Leslie may prefer a lighter, non-amplified Hammond instead of paying for the onboard sound system.

Constraints

Power150-watt onboard sound system
Controls1) Catalog mislabels it as a 'Synthesizer'; every source (manufacturer and retailers) d...

To use it

Required compatible power and data connections, monitoring or MIDI setup as required

Questions

3 to ask before buying

What firmware, software, storage, and synchronization features are supported by this exact model?

Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.

Which power supply, adapters, and included accessories ship with the retailer offer?

Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.

Will its audio, MIDI, and computer connections fit the intended setup without additional hardware?

Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.

Description

Product details

The Hammond A-162 is a digital console organ modeled on the 1960s Hammond A-100 and built around the same VASE III tone engine as Hammond's flagship B-3mk2. It has two 73-key waterfall manuals (61 playing keys from C1 to C6 plus 12 reverse-color preset keys each), nine harmonic drawbar pitches per manual, and a detachable 25-note radiating pedalboard with two drawbar pitches. It is self-contained, with a 150-watt onboard sound system driven by three 50-watt RMS amplifiers into five speakers including a 15-inch woofer, plus a built-in two-rotor Digital Leslie. Classic Hammond features include Touch-Response Percussion, scanner-style Vibrato and Chorus (V1-V3/C1-C3), digital overdrive, and an 11-program digital reverb. Connections include MIDI in/out, stereo line in/out, a microphone input, headphones, and an 11-pin jack for an external Leslie cabinet.
