MILLENNIA HV-316/8 — Microphone
MILLENNIA HV-316/8 — Microphone
Millennia HV-316/8 is the 8-channel version of Millennia's HV-316 remote-controlled network microphone preamplifier. Millennia describes the HV-316 platform as an 8- or 16-channel road-hardened 1U preamp using HV-3 microphone preamplifier circuitry with Dante output standard and optional MADI or analog outputs.
Specifications
Format and Networking
| Channels | 8 channels; factory-upgradable to 16 channels |
|---|---|
| Rack format | 1U rackmount |
| Network audio | Dante output standard with dual RJ-45 Primary/Secondary ports |
| Optional outputs | MADI and analog output options |
Preamplifier
| Preamp circuit | Millennia HV-3 double-balanced microphone preamplifier circuitry |
|---|---|
| Gain range | 1 dB minimum gain; 64 dB maximum gain in 1 dB steps |
| Pad | -20 dB attenuator pad |
| Phantom power | +48 V dc ±2 V dc, 15 mA per channel in reserve |
Performance
| Ein | -130 dB EIN at 60 dBu gain, 10 Hz-30 kHz, inputs common |
|---|---|
| Thd n | <0.005%, typical <0.001% at 35 dB gain |
| Maximum input level | +34 dBu with pad in |
| Maximum output level | +22 dBu with analog output option |
Power and Audio Network
| Ac power | Universal 80-264 V, 47-63 Hz |
|---|---|
| Dc power | 12 V DC supported |
| Sample rates | 44.1, 48, 88.2, 96, 176.4 and 192 kHz |
| Minimum dante latency | 250 µs |
Fit and constraints
Intended use
Constraints
To use it
Questions
Which connections, drivers, operating systems, and sample rates are supported by this exact revision?
Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.
What cables, mounts, power supplies, or licenses are included?
Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.
Is the current retailer listing new stock, demo stock, open box, or special order?
Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.
Description
Millennia HV-316/8 is the 8-channel version of Millennia's HV-316 remote-controlled network microphone preamplifier. Millennia describes the HV-316 platform as an 8- or 16-channel road-hardened 1U preamp using HV-3 microphone preamplifier circuitry with Dante output standard and optional MADI or analog outputs. The HV-316-8 is short-loaded with eight channels and can be factory-upgraded to sixteen channels. Published specifications include 1 dB minimum gain, 64 dB maximum gain in 1 dB steps, -20 dB pad, +34 dBu maximum input level with pad, -130 dB EIN at 60 dB gain, +48 V phantom power, dual RJ-45 Dante ports supporting redundant or switched modes, 44.1-192 kHz sample rates, 19 x 1.75 x 16 in dimensions and 9 lb weight for the 8-channel version.
