MILLENNIA LOCi — Preamp / DI
MILLENNIA LOCi — Preamp / DI
The Millennia LOCi is a phonographic preamp for vinyl and shellac record mastering, featuring selectable RIAA and 78 RPM equalization curves, support for moving-magnet and moving-coil cartridges with adjustable input loading, and both fixed and variable balanced/unbalanced outputs in a 2U rackmount chassis.
Specifications
Gain & Noise
| Maximum System Gain | 60 dB nominal (higher upon request) |
|---|---|
| Broadband Noise (EIN, flat) | Better than -125 dBu EIN, flat |
| EIN, RIAA in | -98 dBu EIN, RIAA in |
| Common Mode Rejection | -75 dBu typical, 10 Hz - 50 kHz |
Levels & Impedance
| Maximum Input | +23 dBu flat |
|---|---|
| Maximum Output | +26 dBu, RIAA in |
| Output Impedance | 49.9 ohms |
| Phono Input Impedance | User selectable. Factory stock: 47.5k ohms & 270 pF |
| Cartridge Support | Balanced phono input supports MC and MM cartridges |
Equalization & Filters
| Filter Boost / Cut | +/-10 dB, 21 detented steps |
|---|---|
| Low Frequency Compensation | 200, 250, 300, 400, 500/RIAA, 700/USER Hz |
| High Frequency Compensation @ 10 kHz | -5.0, -7.0, -9.5, -11.5, -13.7/RIAA, -16.0/USER dB @ 10 kHz |
| Low Filter Frequencies | 20, 35, 60, 100, 180, 260 Hz |
| High Filter Frequencies | 1.0, 2.0, 3.0, 5.0, 8.0, 12.0 kHz |
| Notch Q Factor | Q = 1.0 |
Frequency Response
| Frequency Response | 10 Hz to 100 kHz (comps & filters out, +45 dB gain), +/-0.5 dB |
|---|
Outputs
| Output Configuration | Phono preamp direct fixed & variable level; unbalanced EQ out (fixed); balanced EQ out (variable) |
|---|---|
| XLR Polarity | Pin 2 = positive, Pin 1 = ground |
Circuit & Topology
| Gain Amplifier | All Discrete J-FET True Differential Gain Amplifier (IMA-01) |
|---|---|
| EQ Servo | All Discrete 50V J-FET Servo (FSA-03) |
| Signal Path | Ultra-premium transformerless design path throughout |
| Transformer Option | Lundahl MC transformer option included at no additional charge |
Power
| Power Consumption | 60 watts nominal |
|---|---|
| Mains Input | 100VAC to 240VAC, 50/60 Hz, user selectable |
| Fuses | 2 x 1.0A (100-120VAC) or 2 x 500mA (200-240VAC), 5x20mm |
Physical
| Dimensions | 19.0" W x 15.0" D x 3.5" H (2U rackmount) |
|---|---|
| Weight | Approximately 26 pounds |
| Construction | Hand-machined aluminum cosmetics; gold relays, connectors & switches |
Fit and constraints
Intended use
Constraints
To use it
Questions
Which connections, drivers, operating systems, and sample rates are supported by this exact revision?
Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.
What cables, mounts, power supplies, or licenses are included?
Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.
Is the current retailer listing new stock, demo stock, open box, or special order?
Ask before you buy via contact. Confirm power, condition grade, and included items against the listing photos.
Description
The Millennia LOCi is a professional phonographic playback preamplifier for archival transfer and mastering of vinyl and shellac records. It provides selectable RIAA and legacy (78 RPM era) equalization curves plus corrective low/high compensation and filters, and supports both moving-magnet and moving-coil cartridges with user-selectable input loading. The signal path uses an all-discrete Class-A J-FET true-differential topology on a transformerless design with an included Lundahl moving-coil transformer option. It offers fixed- and variable-level, balanced and unbalanced outputs in a 2U rackmount, hand-machined aluminum chassis with worldwide mains operation.
