A JAM Pedals Eureka! fuzz guitar pedal in a hand-painted enclosure showing artwork of a rubber duck sitting in a bathtub, with three control knobs, a small three-way toggle switch, a footswitch, and the JAM logo at the bottom.

JAM Pedals Eureka! Fuzz 2010s - Hand Painted

$219.20
$219.20
Skip to product information
A JAM Pedals Eureka! fuzz guitar pedal in a hand-painted enclosure showing artwork of a rubber duck sitting in a bathtub, with three control knobs, a small three-way toggle switch, a footswitch, and the JAM logo at the bottom.
  • A JAM Pedals Eureka! fuzz guitar pedal in a hand-painted enclosure showing artwork of a rubber duck sitting in a bathtub, with three control knobs, a small three-way toggle switch, a footswitch, and the JAM logo at the bottom.
  • A JAM Pedals Eureka! fuzz guitar pedal in a hand-painted enclosure showing artwork of a rubber duck sitting in a bathtub, with three control knobs, a small three-way toggle switch, a footswitch, and the JAM logo at the bottom.
JAM Pedals Eureka! Fuzz 2010s - Hand Painted

JAM Pedals Eureka! Fuzz 2010s - Hand Painted

JAM Pedals Eureka! Fuzz 2010s - Hand Painted — sourced facts: 20% on Custom & Standard Art pedals: code BLACK20; Effect Type: Fuzz; Transistor Architecture: Silicon transistors (proprietary architecture); Tonal Character: Germanium-style mid-range + Muff-style fuzz distortion.

$219.20
$219.20
Condition Excellent
Specs Verified model facts
In stock Ask a question

Specifications

Fuzz · True Bypass · 9V battery or 9V DC (center-negative)
20% on Custom & Standard Art pedals code BLACK20
Effect Type Fuzz
Transistor Architecture Silicon transistors (proprietary architecture)
Tonal Character Germanium-style mid-range + Muff-style fuzz distortion
Gated-Fuzz Mode Gated-fuzz response at top toggle position (with hot signal)
Level Level (output)
Tone Tone
Gain Gain
Bass Boost Toggle 3-way bass boost toggle (0 / +1 / +2)
Status LED On/off status LED
Bypass True Bypass
Input 1/4" input jack
Dimensions (jacks & pots included) 11.1 x 7 x 4.8 cm (4.3 x 2.7 x 1.8 in)
Weight 230 g / 0.5 lbs
Dimensions note 2.1 mm center-negative DC jack Physi
Format Eurorack
Power Supply 9V battery or 9V DC (center-negative)
Current Draw 8 mA
Power 9V battery or 9V DC (center-negat

Fit and constraints

9V battery or 9V DC (center-negative)

Intended use

Not for Players who specifically want a genuine vintage germanium fuzz — the Eureka! uses silicon transistors and only voices germanium-like mid-range, so it is not a true germanium circuit. Also skip if you need a blend/clean-mix control, onboard presets, or a battery-free/USB-powered pedal.

Constraints

Power9V battery or 9V DC (center-negative)
BypassTrue Bypass

To use it

Description

Product details

The JAM Pedals Eureka! is a handmade fuzz guitar effects pedal built by JAM Pedals in Greece. It uses silicon transistors in a proprietary circuit that combines the mid-range voicing of germanium-style fuzz with a Big Muff-style fuzz distortion. Controls are Level, Tone, and Gain knobs plus a three-way toggle that adds increasing amounts of bass boost (0, +1, +2), with the top toggle position producing a gated-fuzz response when fed a strong enough signal. It is true bypass, runs on a 9V battery or a center-negative 9V DC adapter drawing 8 mA, and each unit is individually hand-painted.
