AnaMod AM660 500 Series module with a VU gain-reduction meter and front-panel controls labeled Input Gain, Threshold, and an eight-position Time Constant selector, plus an IN hard-bypass switch.

AnaMod AM660 500 Series Compressor & Limiter

$1,917.99
$1,917.99
Skip to product information
AnaMod AM660 500 Series module with a VU gain-reduction meter and front-panel controls labeled Input Gain, Threshold, and an eight-position Time Constant selector, plus an IN hard-bypass switch.
  • AnaMod AM660 500 Series module with a VU gain-reduction meter and front-panel controls labeled Input Gain, Threshold, and an eight-position Time Constant selector, plus an IN hard-bypass switch.
  • AnaMod AM660 500 Series module with a VU gain-reduction meter and front-panel controls labeled Input Gain, Threshold, and an eight-position Time Constant selector, plus an IN hard-bypass switch.
AnaMod AM660 500 Series Compressor & Limiter

AnaMod AM660 500 Series Compressor & Limiter

AnaMod AM660 500 Series Compressor & Limiter — sourced facts: Connectivity: Usb; Position: Attack Time; 2a: 0.2 ms; 2b: 0.2 ms.

$1,917.99
$1,917.99
Condition Excellent
Specs Verified model facts
In stock Ask a question

Specifications

127 mA when engaged
Connectivity Usb
Position Attack Time
2a 0.2 ms
2b 0.2 ms
Input Impedance 20 kΩ, balanced
Output Impedance less than 50 Ω
Input Gain -15 to +15 dB
Max. Output Level +27 dBu, balanced
Frequency Response +/- 1 dB from 40 Hz to 15 kHz
Noise Level better than 73dB below +4 dBu, 0-30 kHz
Limiting Noises same level as a vintage 660 with GE five star 6386 tubes and properly balanced
Audio resolution 15 kHz
Format 1U
Weight 1.3 lbs (0.6 kg)
Current draw 127 mA when engaged

Fit and constraints

127 mA when engaged

Intended use

Not for Anyone needing stereo processing from one slot (it is a single-channel module; two units are required for a stereo buss), precise recallable threshold/ratio values (ratio is variable and level-dependent, not dialed in numerically), or a self-contained unit -- it requires an API 500 Series or compatible rack with XLR wiring and is not standalone.

Constraints

Power127 mA when engaged

To use it

Description

Product details

The AnaMod AM660 is a single-channel 500 Series compressor and limiter that recreates the Fairchild 660 using AnaMod's analog modeling process, implemented entirely in the analog domain with no A/D or D/A conversion and no latency. It is a feedback compressor whose compression ratio is variable and level-dependent, from 1:1 to 20:1. Front-panel controls are Input Gain, Threshold, an eight-position Time Constant selector, and a hard-bypass (IN) switch, along with a VU meter that reads the actual amount of gain reduction in dB. The module installs in an API 500 Series or equivalent rack and draws about 127 mA when engaged.
